DESCRIPTION
Digital thermal imaging scopes Quantum based on IR sensor (uncooled
microbolometer) are represented by a number of models featuring
various frame rate, magnification and lens diameter. The scopes are
designed for the use both in the nighttime and in the daylight in inclement
weather conditions (fog, smog, rain) to see through obstacles hindering
detection of targets (branches, tallgrass, thick bushes etc.). Unlike the
image intensifier tube based night vision devices, thermal imaging
scopes Quantum do not require an external source of light and are not
affected by bright light exposure.
The Quantum XD series features stadiametric rangefinder, multiple
color modes and 50 Hz frame rate.
Thermal imaging scopes Quantum have a wide range application
including night hunting, observation and terrain orientation, search and
rescue operations.
FEATURES
Detector size 384x288 pixels
Quality OLED display (640x480 pixels)
Stadiametric rangefinder*
Multiple color modes*
Optical magnification 1.1x/2.1x/2.8x
2x (LD series) / 2x-4x (XD series) digital zoom
Display off function*
Three calibration modes - manual, semiautomatic and automatic
Three operation modes - city, forest, identification
Defective pixel repair option
Power saving mode
Wide field of view
External power supply
Video output enabling recording
Image inversion modes: “White hot” and “Black hot”
Two ¼” tripod mounts
* Available in XD series only.
2
PACKAGE CONTENTS
For improvement purposes, design of this product is subject to change.
Thermal Imaging Scope
Carrying case
User manual
Video cable
Hand strap
1
SKU
Optical characteristics:
Type
Refresh rate
Magnification, x
Digital zoom, x
Resolution, pixels
Resolution, pixel
Close-up range, m
Exit pupil, mm
Spectral range, µm
Diopter adjustment, D
Max. detection range, m/yd*
Operational characteristics:
Start-up time, sec
Power supply
Battery type
External power supply
Operating time on battery
pack EPS3 / EPS5), h
Operating time on a battery
set**, h, approx.
Degree of protection, IP
code (IEC60529)
Uncooled
Uncooled
Field of view, degree / m@100m
- horizontal
- vertical
SPECIFICATIONS:
MODEL
384x288
640x480
5
7.7-13.2
+5/-5
1250 / 1367
8,4-15 V
IPХ4
5
9
4÷6 V
4xАА
9 / 20
11 / 19.2
8.3 / 14.4
5,5
Microbolometer:
Display:
Type
384x288
640x480
3
7.7-13.2
+5/-5
950 / 1039
8,4-15 V
IPХ4
8
9
4÷6 V
4xАА
9 / 20
14.4 / 25
10.8 / 19
5,5
OLED
2
2
2
384x288
640x480
3
7.7-13.2
+5/-5
500 / 547
8,4-15 V
IPХ4
8
9
4÷6 V
4xАА
9 / 20
26.8 / 50.5
20.8 / 38
5,5
OLED OLED
Uncooled
9 Hz
9 Hz
9 Hz
Objective lens
19 mm, F/1.2 38 mm, F/1.2 50 mm, F/1.2
Video output
Operating temperature
PAL/NTSC
PAL/NTSC
PAL/NTSC
2
*
Max. detection range of an object measuring 1.7x0.5 m
Operation in power saving mode.
Dimensions, mm
inch
Weight (without batteries), kg / oz
-25 °С to +50 °С / -13 °F to +122 °F
0.43 / 15.2
207x86x59
8.1x3.4x2.3
**
0.35 / 12.3
200x86x59
7.9x3.4x2.3
0.32 / 11.3
180x86x58
7x3.4x2.3
Quantum XD50S Quantum XD38S Quantum XD19S
2.8 - 5.6
2.1 - 4.2
1.1 - 2.2
77322
LD50S
77312
LD38S
77314
LD19S
XD19S XD38S
XD50S
77315 77316 77317
50 Hz
50 Hz
50 Hz
1.1 - 4.4
2.1 - 8.4
2.8 - 11.5
2 / 4
2 / 4 2 / 4
Body color
green black green black green black
Automotive cigarette lighter adapter
Spare battery container
Cleaning cloth
Warranty card
