Pumpex K 101 - Wiring Diagram

14 (15)
K 101/151/200/250/300.58.0404.Eng/Digital
SERVICE INSTRUCTION
K 101, 151, 200, 250, 300
ÄY
1
2
Y/Ä
3
THERMAL PROTECTION WINDING
MOISTURE SENS. OIL CHAMBER MOISTURE SENSOR TERMINAL BOARD AREA
Star/Delta starting
THERMAL PROTECTION WINDING
MOISTURE SENS. OIL CHAMBER MOISTURE SENSOR TERMINAL BOARD AREA
Direct on-line starting
THERMAL PROTECTION WINDING
MOISTURE SENS. OIL CHAMBER MOISTURE SENSOR TERMINAL BOARD AREA
Direct on-line starting
Wiring Diagram
