SERVICE INSTRUCTION
K 101, 151, 200, 250, 300
Torque Rating
Cable Gland: A specific torque value cannot be given for the cable gland. Tighten it until
the rubber offers resistance, and thereafter, one more full rotation.
Size [Nm] [lb-ft]
M6 7 5.2
M8 17 12.5
M10 33 24.3
M12 57 42.0
M14 91 67.1
M16 140 103.3
Size [Nm] [lb-ft]
Impeller Bolt
198 146
(M16 Bumax)
Latch Bolt
187 138
(M16 A4-80)
