Pure Humidifier EC-15 Installation Instructions

19
Recommended Maintenance Tool List
7/16” Wrench
5/16” Nut Driver or Socket
11/32” Nut Driver or Socket
3/8” Nut Driver or Socket
5/32” Nut Driver or Socket
Flat head screwdriver
Wire stripper
Wire crimper
Tool Requirements & Torgue List
Torque List
Cover Bolts 18 inch/pounds MAX
Hose Cuff Screws 35-40 inch/pounds MAX when hot
Heater Nut 18-20 foot/pounds*
Heater Electrical Terminal 35 inch/pounds
* Use a pliers to hold heater sheath from twisting.
Cover
Heater Fiber Gasket
Heater Nut
Electrical Terminal Nuts
Metal Washer
Heating Element Sheath
Isolator
Heater Assembly Sectional Detail
