PURE Humidifier Co. “EC” Series
Parts List & Two Year Recommended Spare Parts
Item No. Description Part No. Qty Rec.
Per Unit. SpareQty.
1 EC Exterior Cabinet 18001 1
2 EC Cabinet Door, no lock, see item 21 18002 1
3 EC Reservoir Assembly A 1
4 EC Reservoir Cover Assembly A 1
5 Immersion Heating Elements A A
6 EC Tri-Probe Sensor 05327 1
7 Tri-Probe O-Ring 15166 1
8 Tri-Probe Set Screw 15525 1
9 Cover Gasket A A
10 Cover Clamp 15930 A
11 Cover Clamp Screws 15522 A
12 10-24 U-Nut 15524 A
13 Overtemp Protection Switch 15047 1
14 Overtemp Switch Housing 15072 1
15 1/4" Stainless Steel Fill Valve with Strainer 09128 1
16 Motorized Drain Valve 09038 1
17 3/4" Brass Ball Valve 09037 1
18 Fill Tube 05781 1
19 Cabinet Cover Plate 18005 1
20 Heater Cover 96038 1
21 Door Lock and Keys 12001 1
22 Heater Contactor A 1
23 Pilot Relay 12018 A
24 Relay Socket 12020 A
25 Fuse Block A 1
26 Heater Fuses A 3
27 Step-Down Transformer A 1
28 Primary Fuse Holder A 1
29 Primary Fuses A 2
30 Control Board A 1
31 Wiring Harness P3-A 18027 1
32 Wiring Harness A A
33 14 Point Terminal Strip 12044 1
34 SCR Relay A A
35 SCR Heat Sink A A
36 Secondary Fuse A 1
37 Power Supply Cover 18008 1
Optional INTAC® Microprocessor Equipped Units
38 Secondary Fuse Holder 12085 1
39 INTAC® Microprocessor A 1
40 6 Pin Terminal Strip 12309 A
41 7 Pin Terminal Strip 12310 A
42 INTAC® EC Wiring Harness A 1
NOTES/CODES:
A = Part Number and quantity vary with model number.
When ordering replacement or spare parts, please have the following information
available: Model Number, Primary Volage, Serial Number, No. of Heaters & Heater
KW and any options (ie, automatic drain, modulating control or insulation etc.)
Some parts shown may not be required for your unit. 7/13/2015
