Hardware Layout (HC Model Shown)
A B C
KEY
A
Inner Circuit Board
B
Outer Circuit Board
C
Terminal Strips
D
DCLMB - Dual Control Loop Module B
E
WLCM - Water Level Control Module
F
DCLMA - Dual Control Loop Module A
E D F
