21
INTAC
®
MENU
DISPLAY
OPTIONS
MFG
DEFAULT
DESCRIPTION
101
RH Set Pt RANGE: 0% to 100% RH 45% Space or return air humidification setpoint
102
HL RH Set Pt RANGE: 0% to 100% RH 80% Supply air high-limit setpoint
103
RH Lo Alarm RANGE: -100% to -1% RH -5% Low humidity alarm activates when actual RH is below setpoint
104
RH Hi Alarm RANGE: 1% to 100% RH 5% High humidity alarm activates when actual RH is above setpoint
201
Operation Mode Normal x Normal operation mode
Stand-by Output of humidifier shut off while in Stand-by mode
Forced Drain Drain valve output energized, humidifier output shut off
Flush Fill valve and drain valve outputs are energized, humidifier output shut
off
202
Drain Duration RANGE: 0 to 120 minutes Varies Time drain valve is energized (in minutes) during Auto-drain cycle
203
Drain Interval RANGE: 1 to 500 Hours 40 Time between Auto-drain cycles in hours of operation
204
Cool Down Delay RANGE: 0 to 150 Seconds 150 The fill valve is energized for this time period to allow colder makeup
water to cool the tank before the Auto-drain cycle begins.
205
Cool Down Temp RANGE: 80° to 212°F 140 The tank water temperature must be below this value before the drain
valve is energized during an Auto-drain cycle. The fill valve is ener-
gized to allow colder makeup water to cool the tank. Used in place of
cool down delay when an optional tank thermocouple is installed
RANGE: 27° to 100° C 60 Same description as above except for Celsius units are used
206
Fill Delay RANGE: 0 to 15 Seconds 5 Water overfill time delay to help flush surface minerals down the tank
overflow on each refill cycle
207
H2O Set Pt RANGE: 40° to 200° F 40 If there is no call for humidification the heating source will be turned
on to maintain this temperature. This can be used for freeze protection
(40°) or stand-by water temperature (160°)
RANGE: 4° to 93°C 4 Same description as above except for Celsius units are used
208
Water Hysteresis RANGE: 1° to 50°F 3 Accuracy of water temperature control or deadband
RANGE: 1° to 28°C 2 Same description as above except for Celsius units are used
209
End of Use Drain RANGE: 0 to 168 Hours 48 When there is no call for humidification for this many consecutive
hours the tank will drain completely.
210
Time to Clean RANGE: 0 to 365 Days 30 Used to set a reminder to clean the tank after an adjustable time peri-
od of run time. The humidifier will continue to operate even after the
“Time to Clean the Tank” message is displayed.
211
Clean Reset Off x Time to clean timer is accumulating run time
On Select “On” to reset the accumulated run time
INTAC
®
Configuration Codes Complete Listing
