15
Hints and tips
The current value for most settings is indicated on the display by an
asterisk (
*
).
Technical specifications
Radio Radio Digital and FM radio
Frequencies DAB/DAB+, FM radio 87.5-108 MHz
Headphones Noise-isolating, 16 Ohm, 10 mm drivers.
Input Micro USB for power supply and software
upgrade.
Output 3.5mm stereo output for headphones.
Mains power Adapter: Input AC 100 - 240 V~,50/60 Hz;
Output DC 5V , 0.8 A;
Main Unit: DC 5V
Part
Project
Sub Assembly
Doc Type
Customer
Version
Version Date
106WV
Marley
Rear Housing
Artwork
Pure
1
07/09/2016
History V1 - 1st Issue
Pantone 877C
Colour Spec
, 0.8 A
Software version V1.2_M_1RC9
Battery ChargePAK M1 1000mAh.
Dimensions 102 mm x 56 mm x 15 mm
Approvals CE marked.
Compliant with R&TTE (RED 2014/53/EU
after 13th June 2017) and RoHS Directives
(1999/95/EC and 2011/65/EU).
ETSI EN300 401 compliant.
See pure.com for the full Declaration of
Conformity.
Help and specifications

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the PURE Move 2520 and is the answer not in the manual?

PURE Move 2520 Specifications

General IconGeneral
Tuner typeAnalog & digital
Supported radio bandsDAB, DAB+, DMB, FM
Radio Data System (RDS)Yes
Preset stations quantity20
RMS rated power- W
Built-in speaker(s)No
Headphone outputs1
USB connector typeMicro-USB
Headphone connectivity3.5 mm
Volume controlDigital
Apple docking compatibilityNot supported
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Battery capacity1000 mAh
Battery life (max)15 h
Weight and Dimensions IconWeight and Dimensions
Depth15 mm
Width56 mm
Height102 mm
Weight105 g
