4
5. Slide the rail into the gap in the footboard between the heel rests. The seat should
be upwards. The rail end should slide in until the holes on the side of the rail line
up with the holes behind the footboard. (You may need to lift tank to slide rail
through.)
6. Install the rail cross bolt (A) through the back of the footboard and rail and into
the rail cross nut (B) (inserted into the opposite side). Do not tighten all the way.
(A) Rail Cross Bolt (B) Rail Cross Nut (E) Allen Keys
7. Install the rail bolt (C) and black washer (F) through the top surface of the rail and
into the footboard. Do not tighten all the way.
(C) Rail Bolt (F) Black Washer (E) Allen Key
