PurePro POSEIDON - Installation Diagram; Tubing Connection Diagram

Install drain saddle :
Drill a 1/4" hole into
the drain pipe.
Mount drain
saddle aligning
holes.
Input water :
To RO system
Deliver valve
Water supply connector
To water
source pipe
Install faucet :
Faucet
Kitchenware table
Twisted plastic locker
Rubber gasket
Flat metal piece
Screw locker
Tubing
Cutting ring
Concave type screw
Installation diagram
Tubing connection diagram
Install membrane :
Remove the tube.
Remove the membrane housing cap.
Install the membrane by carefully
pushing the spigot end into the
socket at the far end of the housing
until completely in.
P
R
O
P
U
R
E
D
R
I
N
K
I
N
G
W
AT
E
R
S
Y
S
T
E
M
Tube
Connecting the color tubing
A. Connect the WHITE tubing to
the water supply connector.
B. Connect the BLUE tubing to
the countertop faucet.
C. Connect the BLACK tubing to
the drain saddle.
AB C
Back view
(A) (B) (C)
