DRAIN OUTLET INLET
S300STS300NDS300RD
DRAIN OUTLET INLET
S300STS300NDS300RD
5
1.Turn off the water supply. Loosen the stainless steel pipe
connector. Get feed water connector and connect it to the
stainless steel pipe.
2.Get tubing white, connect it with deliver valve and the
inlet water supply.
DRAIN OUTLET INLET
S300STS300NDS300RD
Cold
5.Make sure that you complete. If so, switch on
water supply and plug in electricity.
PS. Do not use drink water from the first made
water in the tank.
2
1
3
4
4.Use an electric drill and drill an approximately 1 cm
hole through the kitchenware table. Take out the faucet
and its components. Install the faucet and the rubber
gasket to the kitchenware table.
Take tubing blue. Wear the concave type screw on
tubing blue and insert the tubing shroud as shown in
the picture. Connect the tubing top with the faucet end.
Then connect the tubing end to the hole of "TO FAUCET".
3.Take tubing black, connect it with the drain out.
Installation diagram
