29
CONNECTING STRAP (ONLY INCLUDED WITH TWIN XL)
Connecting straps are secured to the base frame upon delivery.
Legs are required for the installation of the connecting straps.
The straps are used for holding two Twin XL bases together for
a Split King.
With the bases in their desired location,
slightly loosen both legs to allow the
strap to t on the leg bolt, between the
leg washer and frame.
Slide side (A) of the connecting strap
onto leg bolt. Swing the strap and con-
nect side (B) to the leg bolt. Secure the
strap by shifting to the left.
Re-tighten legs. Do not overtighten.
Use the remaining strap and repeat on
other end of the base.
1
2
3
A B
