32
3
2
Attach the plastic spacer and T-Bracket.
A
B
You may now connect your headboard to the attachment plates using the remaining short
bolts and nuts to secure it to the brackets. The heads of the bolts will face outward. Use a
9/16" socket and 1/2" wrench to tighten the bolts.
HEADBOARD BRACKET INSTALLATION GUIDE OPTIONAL
Measure the distance between the
mounting holes on the headboard and
install the spacer and attachment plate
to accommodate the headboard.
To install the plastic spacer and at-
tachment plate, you will need (2) long
bolts and (2) nuts. Place the spacer
and attachment plate in the desired
location and slip the bolts through the
holes with the head of the bolt facing
outward. Position the bolts diagonally
on the spacer. Use the 9/16” socket and
wrench to tighten the bolts.
