LIMITED 2 YEAR WARRANTY
Putco guarantees it’s Stainless Steel and Aluminum products against defects in workmanship and material for as long as you own
your vehicle. All painted products have a 90 day warranty on the painted surface. Any defects resulting from faulty material or
workmanship will be warranted by Putco and repaired or replaced at our discretion. Putco assumes no extra labor costs. Damages
caused by freight carriers, improper installation, misuse, collision, or neglect will not be warranted by Putco.
07/08/2015 JLS 4RINST-F150
Fog Lamp Removal
1.
From the backside of the bumper disconnect the factory wiring harness from the fog lamps. Refer to
Figure 1.
2.
Remove adjusting screw and spring. Set aside as they will be required later. Refer to Figure 1.
3.
Use a flat bladed screwdriver to press out the tension clips on the fog lamp mounting bracket. Pull
Fog Lamp out of housing from the front side of the bumper. Refer to Figure 2.
Figure 1
Lift tab and pull back
Requires a short Phillips
screwdriver to remove
Press in here
Figure 2
Two Places
To Next Page
