PVI VeCOAX - Device Layout

Pro Video Instruments
VeCOAX Network Compact HDMI RF Modulator Manual
3
DEVICE LAYOUT
1) Network Port (Ethernet)
5) HDMI Input
2) GREEN Power Indicator Light
6) RST - Reset Button
3) BLUE On-Air Indicator Light
7) Power In (12V 1A DC)
4) RF Coax Connector
