20060517 1-18-1 E7A02EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DVD MECHANISM & DVD MAIN CBA
ASSEMBLY
AV ASSEMBLY
AV CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DVD MECHANISM & DVD MAIN CBA
ASSEMBLY
N78F3CUN
Ref. No. Description Part No.
AV ASSEMBLY
Consists of the following:
1VSA12795
AV CBA (SUB-A)
SW CBA (SUB-B)
----------
----------
Ref. No. Description Part No.
AV CBA (SUB-A)
Consists of the following:
----------
CAPACITORS
C1001# ACROSS THE LINE CAP. 0.068µF/250V CT2E683DC016
C1002# SAFETY CAP. 2200pF/250V CCD2EMA0E222
C1003 ELECTROLYTIC CAPACITOR
ZR200TA151K16DB
CA2D151DYG03
C1004 CERAMIC CAP. B K 0.01µF/500V CCD2JKP0B103
C1005 CERAMIC CAP. B K 220pF/500V CCD2JKP0B221
C1006 CERAMIC CAP.(AX) X K 5600pF/16V CCA1CKT0X562
C1007 CERAMIC CAP.(AX) CH J 56pF/50V CA1J560TU008
C1008 CERAMIC CAP.(AX) B K 3300pF/50V CA1J332TU011
C1009 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1010 FILM CAP.(P) 0.022µF/50V J CMA1JJS00223
C1015 CERAMIC CAP. B K 220pF/500V CCD2JKP0B221
C1051 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1052 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1053 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1055 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C1056 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1057 ELECTROLYTIC CAP. 1000µF/6.3V M(105°C) CE0KMASTH102
C1058 ELECTROLYTIC CAP. 3300µF/6.3V M(105°C) CE0KMZATH332
C1059 CERAMIC CAP. CH J 47pF/50V CCD1JJSCH470
C1060 ELECTROLYTIC CAP. 4700µF/6.3V M(105°C) CE0KMZATH472
C1061 ELECTROLYTIC CAP. 2200µF/6.3V M(105°C) CE0KMASTH222
C1063 ELECTROLYTIC CAP. 1000µF/16V M(105°C) CE1CMASTH102
C1064 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1065 CHIP CERAMIC CAP.(1608) B K 0.033µF/50V CHD1JK30B333
C1066 CERAMIC CAP. B K 220pF/500V CCD2JKP0B221
C1067 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1068 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1070 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1074 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1075 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1076 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1080 CHIP CERAMIC CAP.(1608) B K 0.033µF/50V CHD1JK30B333
C1081 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1082 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1084 CHIP CERAMIC CAP.(1608) B K 0.033µF/50V CHD1JK30B333
C1085 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C1101 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1102 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1121 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1122 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1123 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C1124 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C1125 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1135 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C1151 ELECTROLYTIC CAP. 47µF/16V M CE1CMASDL470
C1152 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C1161 ELECTROLYTIC CAP. 47µF/16V M CE1CMASDL470
C1171 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C1172 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C1175 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1176 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1181 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C1182 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C1185 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1186 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1201 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1202 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1203 CHIP CERAMIC CAP.(1608) CH J 270pF/50V CHD1JJ3CH271
C1204 CHIP CERAMIC CAP.(1608) CH J 270pF/50V CHD1JJ3CH271
C1205 CHIP CERAMIC CAP.(1608) CH J 47pF/50V CHD1JJ3CH470
C1206 CHIP CERAMIC CAP.(1608) CH J 47pF/50V CHD1JJ3CH470
C1211 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1212 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1221 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1222 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1241 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1245 ELECTROLYTIC CAP. 47µF/16V M CE1CMASDL470
C1301 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1302 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1303 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1304 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1305 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1306 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1313 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1314 ELECTROLYTIC CAP. 22µF/16V M CE1CMASDL220
C1315 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1316 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1331 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C1332 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C1333 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1334 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
Ref. No. Description Part No.
