20060517 1-18-2 E7A02EL
C1335 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1336 PCB JUMPER D0.6-P5.0 JW5.0T
C1337 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1338 ELECTROLYTIC CAP. 100µF/6.3V M NP CP0KMASNC101
C1405 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1406 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1407 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1408 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1409 ELECTROLYTIC CAP. 22µF/16V M CE1CMASDL220
C1410 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1411 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1413 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1414 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1415 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1417 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1418 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1419 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1420 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1421 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1501 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1502 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1503 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1506 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C1507 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C1508 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
If C1509 is 0.015µF, then IC1502 is R3112N191A-TR-FA or BU4219G-TR.
C1509 CHIP CERAMIC CAP.(1608) B K 0.015µF/50V CHD1JK30B153
IC1502 VOLTAGE DETECT R3112N191A-TR-FA or QSZBA0TRC021
RESET IC BU4219G-TR QSZBA0TRM090
If C1509 is 0.1µF, then IC1502 is PST3619NR.
C1509 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
IC1502 SYSTEM RESET IC PST3619NR QSZBA0TMM151
C1510 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C1512 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C1513 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C1516 CHIP CERAMIC CAP.(1608) CH D 10pF/50V CHD1JD3CH100
C1518 CHIP CERAMIC CAP. CH C 2pF/50V CHD1JC3CH2R0
C1573 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1575 ELECTROLYTIC CAP. 100µF/6.3V M(105°C) CE0KMASTH101
C1576 ELECTROLYTIC CAP. 100µF/6.3V M(105°C) CE0KMASTH101
C1577 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1578 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1701 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1702 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1703 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1704 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C1706 CHIP CERAMIC CAP.(1608) B K 0.033µF/50V CHD1JK30B333
C1708 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1709 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1712 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C1713 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
C1714 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
C1715 ELECTROLYTIC CAP. 0.33µF/50V M CE1JMASDLR33
C1716 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1718 ELECTROLYTIC CAP. 4.7µF/50V M CE1JMASDL4R7
C1719 ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
C1720 ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
C1721 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1722 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1723 ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
C1724 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1725 ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASDL3R3
C1726 ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASDL3R3
Ref. No. Description Part No.
C1727 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1728 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C1729 ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
C1730 CHIP CERAMIC CAP.(1608) B K 0.033µF/50V CHD1JK30B333
C1731 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
C1732 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C2001 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C2002 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C2003 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C2004 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C2005 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C2006 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C2007 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C2008 ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASDL3R3
C2009 ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASDL3R3
C2010 ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASDL3R3
DIODES
D1001 DIODE 1N5397-B NDLZ001N5397
D1002 DIODE 1N5397-B NDLZ001N5397
D1003 DIODE 1N5397-B NDLZ001N5397
D1004 DIODE 1N5397-B NDLZ001N5397
D1005 PCB JUMPER D0.6-P5.0 JW5.0T
D1006 RECTIFIER DIODE BA157 NDQZ000BA157
D1007 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1008 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1009 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1010 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1011 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1012 ZENER DIODE DZ-18BSBT265 NDTB00DZ18BS
D1014 RECTIFIER DIODE BA157 NDQZ000BA157
D1051 SCHOTTKY BARRIER DIODE SB140 NDQZ000SB140
D1053 ZENER DIODE DZ-20BSBT265 NDTB00DZ20BS
D1054 RECTIFIER DIODE BA157 NDQZ000BA157
D1055 SCHOTTKY BARRIER DIODE SB140 NDQZ000SB140
D1056 SCHOTTKY BARRIER DIODE SB240-B/P NDWZ000SB240
D1058 SCHOTTKY BARRIER DIODE SB340 NDQZ000SB340
D1060 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1061 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1062 ZENER DIODE DZ-4.3BSAT265 NDTA0DZ4R3BS
D1063 RECTIFIER DIODE FR302 NDWZ000FR302
D1064 ZENER DIODE DZ-13BSBT265 NDTB00DZ13BS
D1065 PCB JUMPER D0.6-P10.0 JW10.0T
D1066 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1067 ZENER DIODE DZ-6.8BSBT265 NDTB0DZ6R8BS
D1068 RECTIFIER DIODE BA157 NDQZ000BA157
D1070 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1071 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1072 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1151 ZENER DIODE DZ-11BSBT265 NDTB00DZ11BS
D1152 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1161 ZENER DIODE DZ-5.6BSBT265 NDTB0DZ5R6BS
D1162 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1503 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1507 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1508 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1701 ZENER DIODE DZ-33BSBT265 NDTB00DZ33BS
ICS
IC1001# PHOTOCOUPLER PS2561A-1(Q) QPEQPS2561A1
IC1101 IC SWITCHING CD4052BNSR NSZBA0TTY091
IC1102 IC OP AMP RC4580IP NSZBA0STY173
IC1201 IC OP AMP UTC4558 NSZBA0S2H001
IC1301 VIDEO SWITCH MM1697AJBE QSZBA0TMM150
Ref. No. Description Part No.
