Pye Video E7A02UD - Page 54

20060517 1-18-3 E7A02EL
IC1401 DRIVER FOR DVD MM1637XVBE QSZBA0TMM102
IC1501 MICROCONTROLLER 8BIT MN101C77AFK1 QSZAB0RMS047
If IC1502 is R3112N191A-TR-FA or BU4219G-TR, then C1509 is 0.015µF.
IC1502 VOLTAGE DETECT R3112N191A-TR-FA or QSZBA0TRC021
RESET IC BU4219G-TR QSZBA0TRM090
C1509 CHIP CERAMIC CAP.(1608) B K 0.015µF/50V CHD1JK30B153
If IC1502 is PST3619NR, then C1509 is 0.1µF.
IC1502 SYSTEM RESET IC PST3619NR QSZBA0TMM151
C1509 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
IC1503 VOLTAGE REGULATOR PQ070XF01SZH QSZBA0SSH054
IC1504 VOLTAGE REGULATOR PQ070XF01SZH QSZBA0SSH054
IC1701 IC MTS DECORDER AN5832SA-E1V QSZBA0TMS003
IC2001 VFD DRIVER/CONTROLLER IC PT6313-S-
TP(L)
NSZBA0TG2007
COILS
L1001# LINE FILTER 27MH TLF14CB2730R4 LLBG00ZTU034
L1006 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L1007 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L1051 CHOKE COIL(47UH) LHL10NB470K LLARKGQTU470
L1052 POWER INDUCTORS TWKBNP-180K LLC180KKV007
L1053 CHOKE COIL 22µH-K LLBD00PKV021
L1054 CHOKE COIL 22µH-K LLBD00PKV021
L1055 CHOKE COIL 22µH-K LLBD00PKV021
L1241 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1242 INDUCTOR(0.47µH K) LAP02TAR47K LLAXKATTUR47
L1301 PCB JUMPER D0.6-P5.0 JW5.0T
L1401 PCB JUMPER D0.6-P5.0 JW5.0T
L1701 CHOKE COIL 22µH-K LLBD00PKV021
L1704 PCB JUMPER D0.6-P5.0 JW5.0T
L2001 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
TRANSISTORS
Q1001 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1002# FET 2SK3757(Q) QFWZ02SK3757
Q1003 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1053 TRANSISTOR S2Y52(FUNAI Q H) QQWZ00S2Y52Q
Q1054 TRANSISTOR (PB FREE) KTA1271-Y-AT/P NQSYKTA1271P
Q1055 TRANSISTOR KTA1267-Y-AT/P NQSYKTA1267P
Q1056 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1057 TRANSISTOR KTC3203-Y-AT/P NQSYKTC3203P
Q1063 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1065 TRANSISTOR (PB FREE) KTA1271-Y-AT/P NQSYKTA1271P
Q1101 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1102 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1151 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1161 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1201 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1202 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1203 TRANSISTOR KTA1267-Y-AT/P NQSYKTA1267P
Q1241 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1303 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1304 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1501 TRANSISTOR KTA1267-Y-AT/P NQSYKTA1267P
Q1502 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1505 NPN TRANSISTOR KRC103M-AT/P NQSZKRC103MP
RESISTORS
R1001# CARBON RES. 1/2W J 3.3M Ω RCX2335DP001
R1002 CARBON RES. 1/4W J 680k Ω RCX4JATZ0684
R1003 CARBON RES. 1/4W J 1.8M Ω RCX4JATZ0185
R1004 CARBON RES. 1/4W J 1.8M Ω RCX4JATZ0185
R1005 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R1006 CARBON RES. 1/4W J 820k Ω RCX4JATZ0824
R1007 METAL OXIDE FILM RES. 2W J 2.2 Ω RN02JZLZ02R2
Ref. No. Description Part No.
R1008 METAL OXIDE FILM RES.(STRAIGHT 1W J 15k
Ω
RN01JZLZ0153
R1009 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R1010 METAL OXIDE FILM RES. 2W J 0.75 Ω RN02R75ZU001
R1011 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1012 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1013 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R1014 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1015 CARBON RES. 1/4W J 470k Ω RCX4JATZ0474
R1016 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1051 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1054 CARBON RES. 1/4W J 10 Ω RCX4JATZ0100
R1055 CARBON RES. 1/4W J 10 Ω RCX4JATZ0100
R1057 PCB JUMPER D0.6-P5.0 JW5.0T
R1058 CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R1059 CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R1060 CHIP RES. 1/10W J 390 Ω RRXAJR5Z0391
R1061 CHIP RES. 1/10W J 470 Ω RRXAJR5Z0471
R1062 CHIP RES. 1/10W J 620 Ω RRXAJR5Z0621
R1063 CHIP RES. 1/10W J 27 Ω RRXAJR5Z0270
R1064 CARBON RES. 1/2W J 680 Ω RCX2JZPZ0681
R1065 CHIP RES. 1/10W J 620 Ω RRXAJR5Z0621
R1066 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R1067 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R1068 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R1070 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R1072 CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R1073 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R1074 CHIP RES. 1/10W J 620 Ω RRXAJR5Z0621
R1075 CARBON RES. 1/2W J 680 Ω RCX2JZPZ0681
R1076 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R1077 CHIP RES. 1/10W J 1.1k Ω RRXAJR5Z0112
R1079 CHIP RES. 1/10W J 1.8k Ω RRXAJR5Z0182
R1080 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1081 CHIP RES.(1608) 1/10W F 2.7k Ω RRXAFR5H0272
R1082 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H0562
R1083 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R1084 CHIP RES. 1/10W J 15k Ω RRXAJR5Z0153
R1085 CHIP RES. 1/10W J 1.8k Ω RRXAJR5Z0182
R1087 CARBON RES. 1/4W G 1.5k Ω RCX4GATZ0152
R1089 CARBON RES. 1/4W J 12k Ω RCX4JATZ0123
R1090 CHIP RES. 1/10W J 1.8k Ω RRXAJR5Z0182
R1092 CHIP RES. 1/10W J 10 Ω RRXAJR5Z0100
R1093 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1094 CHIP RES. 1/10W J 120 Ω RRXAJR5Z0121
R1097 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R1101 CHIP RES.(1608) 1/10W F 68k Ω RRXAFR5H0683
R1102 CHIP RES.(1608) 1/10W F 68k Ω RRXAFR5H0683
R1103 CHIP RES.(1608) 1/10W F 68k Ω RRXAFR5H0683
R1104 CHIP RES.(1608) 1/10W F 68k Ω RRXAFR5H0683
R1105 CHIP RES.(1608) 1/10W F 62k Ω RRXAFR5H0623
R1106 CHIP RES.(1608) 1/10W F 62k Ω RRXAFR5H0623
R1107 CHIP RES. 1/10W J 18k Ω RRXAJR5Z0183
R1108 CHIP RES. 1/10W J 18k Ω RRXAJR5Z0183
R1109 CHIP RES. 1/10W J 18k Ω RRXAJR5Z0183
R1110 CHIP RES. 1/10W J 18k Ω RRXAJR5Z0183
R1111 CHIP RES. 1/10W J 18k Ω RRXAJR5Z0183
R1112 CHIP RES. 1/10W J 18k Ω RRXAJR5Z0183
R1113 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1114 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1115 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R1116 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R1117 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
Ref. No. Description Part No.
