Pyle Invincible Series User Manual

www.PyleUSA.com
2
INTRODUCTION
PYLE ampliers provides high-performance sound reinforcement for your
mobile audio equipment. Its versatility enables compatibility with optional
Equalizers, Frequency Dividing Crossover Networks, and other audio processors
in customized system. The Multi-Mode bridging capabilities allow exibility in
hosting several dierent speaker congurations.
To achieve optimum performance, it is highly recommended that you read this
Owners Manual before beginning installation.
WARNING!
High powered audio systems in a vehicle are capable of generating "Live Concert”
high levels of sound pressure. Continued exposure to excessively high volume
sound levels may cause hearing loss or damage.
Also, operation of a motor vehicle while listening to audio equipment at high
volume levels may impair your ability to hear external sounds such as; horns,
warning signals, or emergency vehicles, thus contributing to a potential trac
hazard. In the interest of safety, PYLE recommends listening at lower volume
levels while driving.
TABLE OF CONTENTS
PLANNING YOUR SYSTEM
WIRING CONNECTION
PANEL LAYOUT
CONTROL FUNCTIONS
SPEAKER CONNECTION
TROUBLESHOOTING GUIDE
SPECIFICATION
3
3
5
8
10
16
17

Pyle Invincible Series Specifications

General

Brand	Pyle
Model	Invincible Series
Category	Amplifier
Language	English
