Pyle Invincible Series User Manual

www.PyleUSA.com
9
7. Auxiliary Outputs
The Auxiliary outputs oer PYLE ampliers easy, unlimited system expansion.
Route RCA, from the line out of the rst amplier to the line input of a second
amplier when using a single source output.
8. GND
Connect this terminal directly to the sheet metal chassis of the vehicle using
the shortest wire necessary to make this connection. Always use wire of the
same gauge or larger than the (+) 12 volt power wire.
The chassis connection point should be scraped free of paint and dirt.
Use only quality crimped and/or soldered connectors scraped free of paint
and dirt. Use only quality crimped and/or soldered connectors
WARNING:
Do not connect this terminal directly to the vehicle battery ground terminal
or any other factory ground points.
9. Remote Turn On
This terminal turns on the amplier when (+) 12 volt is applied to it.
Connect it to the remote turn on lead of the head unit or signal source.
10. (+) 12 Volt Power
Connect this terminal through a FUSE or CIRCUIT BREAKER to the positive
terminal of the vehicle battery or the positive terminal of an isolated audio
system battery.
WARNING:
Always protect this power wire by installing a fuse or circuit breaker of the
appropriate size within 12 inches of the battery terminal connection.
11. FUSE
These fuses protect the amplier against internal electrical damage and are
meant to protect the amplier only. All other power connections should be
fused at the source.
12. SPEAKERS: Connect subwoofers to these terminals.
