2 Channel Amplifier - Features
PDA 3000/PDA 6000
X-OVER SELECT
This switch will route the output of the full range
(FULL), or a low pass (LP), or the output of the high
pass (HP) filter to the internal power amplifier
INPUT LEVEL
This allows you to match the amplifier
input sensitivity to the output level of the
source (head unit)
OUTPUT
Provides a full range line level
(RCA) output that allows the use
of additional amplifiers
INPUT
Accepts line level (RCA) inputs from
0.2 to 5 Volts
BASS BOOST
Allows you to adjust the bass
boost from 0dB up to 12dB
MODE SELECT
Allows you to chose “STEREO” or
“MONO” operations
REMOTE CONTROL (only PDA 6000)
These jack are for use with the enclosed remote
control. Only the low pass signal will be controlled.
PROTECT - LED
It indicates the fault operation of the amplifier. When the fault
conditions (overload, excessive heat or short circuit of
speaker) arise, the protection curcuit is engaged to protect
both the speakers and the amplifier against damage.
POWER - LED
It indicates amplifier has turn on
signal
FREQ ADJUST
The built in high&low pass filter is fully variable
from 50Hz to 250Hz, with a rolloff of
12dB/octave
20
