Pyle PDWM4300 User Manual

www.PyleUSA.com
SPECIFICATIONS
A. Overall System
• Oscillation Mode: Quartz Controlled
• Carrier Frequency Range: VHF 174-216MHz
• Stability: ±0.005%
• Max Deviation: ±56KHz with level limiting
• Dynamic Range: >100dB
• S/N Ratio: ≥80db
• T.H.D.: ≤0.5%
• Squelch: “Pilotone & Noise Lock” dual squelch circuit
• Frequency Range: Up to 240 Feet
B. Receiver
• Sensitivity: 6dBµ V at S/N>90dB
• Image Rejection: >60dB
• Stability: >80dB
• Audio Output: -12dB/600ohms unbalanced and balanced
• Power Supply: 15VDC/0.5A
• Dimensions (m/m): 16.5x8.2x1.8 inch
C. Transmitter
• Mike Capsule: Dynamic Microphone (Handheld mic)
Condenser Microphone (Headset mic/clip-on mic)
• Antenna: Built-in Housing (Handheld Transmitter)
External (Belt pack Transmitter)
• RF Output: <10mW
• Spurious: <-40dB
• Battery: one 9V Battery
9

Pyle PDWM4300 Specifications

General

Type	-
Connectivity technology	Wireless
Maximum operating distance	73.15 m
Depth (imperial)	8.2 \
Width (imperial)	16.5 \
Height (imperial)	1.8 \
On/off switch	Yes
Product color	Black
