1. Before Operation...........................................................................................3
1.1 Glossary................................................................................................ 3
1.2 Precautions............................................................................................3
1.3 Maintenance and Cleaning of Discs..........................................................4
1.4 Battery Information of the Remote Control.................................................4
1.5 The Remote Control Description...............................................................5
1.6 The Locations and Names of Controls on or in the unit................................6
1.7 Wires Connection Description..................................................................7
1.8 Unit Installation.......................................................................................8
2. Common Operation........................................................................................9
3. Radio Operation...........................................................................................10
4. Disc, USB and Card Operation......................................................................11
4.1 Load/unload Disc, USB or Card...............................................................11
4.2 Pause Playback.....................................................................................13
4.3 Stop Playback .......................................................................................13
4.4 Select Chapter/Track with the >>|/|<< Buttons..........................................13
4.5 Select Chapter/Track with the Number Buttons.........................................13
4.6 Select Chapter/Track with the Root/PBC Menu.........................................13
4.7 Playback with Speed..............................................................................14
4.8 Playback with Slow Speed......................................................................14
4.9 Display Still Frame Step by Step.............................................................15
4.10 Playback Repeatedly...........................................................................15
4.10.1 One/All Repeat.................................................................................15
4.10.2 A-B Repeat.......................................................................................15
4.11 Playback in Scan Mode.........................................................................16
4.12 Playback from a specified Chapter/Track or a Specified Time...................16
4.13 Playback in Random.............................................................................16
4.14 Playback in Different View-Angle...........................................................16
4.15 Playback in Zoom Mode........................................................................16
4.16 Change the Caption Language..............................................................17
4.17 Change the Audio Language.................................................................17
4.18 Change the Video Signal System..........................................................17
4.19 Look over the Playback Status..............................................................17
4.20 Program Playback...............................................................................18
4.21 Playback IMAGE files..........................................................................18
4.22 Playback MP4 files..............................................................................19
4.23 ESP and Function..........................................................................19
4.24 The DVD System Menu Setup Operation................................................19
* The Region Code.................................................................................23
5 The Trouble Shooting...................................................................................24
6. Specification...............................................................................................25
Contents
ID3
.
6. Specification
General Specification
Power Supply Requirement..................................................DC 12V
Maximum Power Output...................4 x 80W(measured at DC 14.4 V)
Dimensions(wxhxd)........................................178 x 50.5 x 162mm
DVD Deck Specification
Format.....................................DVD/VCD/JPEG/MP4/MP3/WMA/CD
Video System....................NTSC/PAL/PAL-M/PAL-N/AUTO(optional)
Audio System..............................................................24 bit/96KHz
Loading System.......................................................... Auto Loading
Mounting Angle.................................................................0 to +/-30
Video
Video Type...................................................................16:9 and 4:3
Video Output level......................................Composite:1.0 0.2Vp-p
Load impedance: 75 ohms
Horizontal Resolution................................................................500
Audio
Audio Output(Analog audio)..........................................2.0 Vrms
Frequency Response.............................20Hz ~ 20KHz(at 1KHz 0 dB)
S/N Ratio(Audio)............................................. 90dB
Separation..............................................................................50dB
Radio
FM Section
Frequency range..............................................87.5MHz - 107.9MHz
Usable sensitivity......................................................................3uV
I.F Frequency....................................................................10.7MHz
AM Section
Frequency..........................................................530KHz - 1710KHz
Specification
Specification
(at 1KHz 0 dB)
Specification
+0
-1.0
