ww w.PyleUSA.com
11
4. Adjust the controls of MIC 1, MIC 2, and PHONO/AUX to the achieve desired
volume and balance. Using the LED power meter The meter LED position indicate
the amplier output power.
Using the MASTER volume control
The MASTER volume control increases or decreases output level gain. To obtain
best performance with the least distortion, be sure to adjust the output level so
that the LED meter does not continually exceed the right extreme of the meter's
range.
CAUTION: Setting output level too high can overdrive the amplier, causing
permanent damage.
Using the MIX BUS jack
You can connect another PT110/ PT210 to this jack to double the size of your PA
system. This lets you use up to four microphones and two turntables (or two
auxiliaryies) sound souces. Use a shield cable with phono plugs at each end, and
connect the cable between the MIX BUS jacks on the back of two ampliers.
For the best results, do not use a cable longer that 6 feet.
Mix Bus Jack
To Next Page
