ww w.PyleUSA.com
3
3. MIC 1 & MIC 2 Jack: Allows you to connect up to two 6.35mm type microphone.
4. LED Level Display Meter
5. MIC Volume Control: Lets you adjust the MIC1/MIC2 sound level.
6. Three Input Sources Mixing Controls: Controls the sound level for each of the
audio input sources.
PHONO/AUX: Select and connect an alternative high level (AUX/CD) or low level
(PHONO) audio sound source.
7. 100 Hz, 1 kHz, & 8 kHz Equalizer Controls: To enhance the sound or tailor the
high, midrange, and low frequencies for each audio source input to the acoustics
of a particular performance environment, you can adjust these equalizer tone
controls.
8. AUX Input Jack: Allows you to connect any high level sound source, such as a
CD player, tape deck, or tuner, to the CD/AUX jack.
9. CONTROL PANEL BUTTON
A. These buttons are only used to control the USB/SD, Wireless BT and FM
functions and doesn’t control other functions.
B. MODE BUTTON: Press this button to select one from USB/SD mode, FM mode
or Wireless BT play mode. USB/SD mode will be set automatically after turning
ON the unit. Automatically plays mp3 les after inserting a USB ash drive or
SD card. You cannot select AUX, CD and DVD input on this button.
C. Each press of the PLAY/PAUSE BUTTON causes the operation to change from
play to pause or from pause to play in the USB/SD mode or Wireless BT mode.
Press the PLAY/PAUSE BUTTON one time to auto scan all frequencies from
87.5MHz to 108MHz in FM mode Press the button to auto scan channels when
you use FM radio for the rst time. After stop searching, the unit will auto
store all the radio channels and play from the rst radio channel. You don't
need to rescanevery FM radio start up.
D. PREV and NEXT BUTTON: Use these two buttons to select previous or next
track, depending on these dierent modes as below.
• In USB/SD mode: Use to select previous or next track.
• In Wireless BT mode: Use to select previous or next track.
• In FM mode: Use to select previous or next radio channel.
10. LED Display: Show MP3/SD/BT/FM information.
11. USB Port and SD card socket: After inserting a USB ash drive/SD Card into
the input terminal, then press the mode button to choose between audio from
the USB port, SD Card input, Wireless BT or FM radio. If you want to use the
Wireless BT, check the below steps.
