Pyle PT110 User Manual

ww w.PyleUSA.com
4
STEPS FOR CONNECTING WITH WIRELESS BT DEVICE
A. Press MODE button under the ID3 display screen and enter into BT mode.
B. Search for the Wireless BT device and nd the BT name “PYLEUSA or BT”
C. Select the PYLEUSA or BT Wireless BT name and wait for the device to pair.
D. The unit will make a sound conrming that the devices have successfully paired.
E. Once paired you can play music from your bt device. You can also use the control
buttons on the unit to select the tracks from your bluetooth device.
12. Voltage Switch: The amplier has selectable input voltage from 110V/60Hz
which is the standard in USA and CANADA. You can also switch the input
voltage to 220V/50Hz for EUROPEAN operation. Please make sure the switch is
in the proper position before operating, otherwise severe damage will result
not cover by the warranty. Please also replace the fuse with proper rating in
this situation (see the SPECIFICATIONS for the fuse rating).
13. GND (GROUND) screw terminal: If you connect a low level audio input source
(turntable) to the PHONO, please connect your turntable's ground wire (usually
black or green) to the amplier’s GND terminal, to avoid a low frequency hum.
You can also use this screw to ground any other system connection.
14. Unswitched AC Accessory Outlet - 300W MAX.
15. PHONO Input Jack: You can connect a low level audio input source, such as a
magnetic cartridge turntable to the L PHONO and R PHONO jacks.
16. AUX/CD Input Jack: Allows you to connect any high level sound source, such
as a CD player, tape deck, or tuner, to the CD/AUX jack.
17. PHONO and AUX/CD Input Selector: Lets you select the input source you
want to connect to the amplier.
18. MIX BUS Jack: Allows you to connect another units to this jack to double the
size of your PA system.
19. Push-Terminal Connectors: Let you easily connect speaker wires directly to
the ampliers.
20. Wireless BT Anntena: Pull the antenna out when using Wireless BT input.
21. FM Anntena: Pull the the antenna when using FM input.
22. DC 4A/12V Input Jack: Allows you to connect the power for amplier from
12-volt battery source.
INSTALLATION GUIDELINES
• Input connections
• The Unit accept a board range of input sources, including:
Microphones (up to two simultaneously)
• Compact Disc (CD) player
• Cassette, Reel-to-Reel or other tape player Radio Tuner
• Magnetic Cartridge Turntable
