www.PyleUSA.com
6
12. Voltage Switch: The amplier has selectable input voltage from 110V/60Hz,
which is standard in the USA and Canada. You can also switch the input
voltage to 220V/50Hz for European operation. Please make sure the switch is
in the proper position before operating; otherwise, severe damage may result,
not covered by the warranty. Please also replace the fuse with the proper
rating in this situation (see the SPECIFICATIONS for the fuse rating).
13. GND (GROUND) screw terminal: If you connect a low-level audio input source
(turntable) to the PHONO input, please connect your turntable's ground wire
(usually black or green) to the amplier’s GND terminal to avoid a low-frequency
hum. You can also use this screw to ground any other system connection.
14. Unswitched AC Accessory Outlet - 300W MAX.
15. PHONO Input Jack: You can connect a low-level audio input source, such as a
magnetic cartridge turntable, to the L PHONO and R PHONO jacks.
16. AUX/CD Input Jack: Allows you to connect any high-level sound source, such
as a CD player, tape deck, or tuner, to the CD/AUX jack.
17. PHONO and AUX/CD Input Selector: Lets you select the input source you
want to connect to the amplier.
18. MIX BUS Jack: Allows you to connect another unit to this jack to double the
size of your PA system.
19. Push-Terminal Connectors: Allow you to easily connect speaker wires directly
to the amplier.
20. Wireless BT Antenna: Extend the antenna when using Wireless BT input.
21. DC 4A/12V Input Jack: Allows you to connect the power for the amplier
from a 12-volt battery source.
INSTALLATION GUIDELINES
• Input Connections
The unit accepts a broad range of input sources, including:
• Microphones (up to two simultaneously)
• Compact Disc (CD) player
• Cassette, reel-to-reel, or other tape player
• Magnetic cartridge turntable
