Pylon Technologies Co., Ltd. Confidential Proprietary 4
3 Veneer Sends, Computer Receives
4 Land
ADD Switch (5)
ADD Switch: 4 ADD switches, to definite different address code for each
battery module when network cascade multiple battery, up to 8 addresses.
The coding and description see "Table 2-3 ADD Switch."
Table 2-3 ADD Switch
Coded Bit
Address Pack Description
1 2 3 4
ON OFF OFF OFF (1) Pack1
Master Pack, Corresponding with
RS232
OFF ON OFF OFF (2) Pack2 Slave Pack1
ON ON OFF OFF (3) Pack3 Slave Pack2
OFF OFF ON OFF (4) Pack4 Slave Pack3
Note: The coded bits 1 to 4 in table separately represent ADD keys from left to right. (set up for
the "ON", down to "OFF"). The address of each device in accordance with the binary
coded bits, 1 is low, 4 is high, Table 2-3 Example 1-4 address coding, 5-8 address and
so on. If several Extra products cascading multiple network devices, the address
encoding 1 is the main battery, others are assistants.
LED Status Indicators (6,7,8)
RUN Lamp (No.6 Figure 2-1): green, long lighting when charging and flash
when discharging;
ALM Lamp (No. 7 Figure 2-1 7): red, flashes when alarm and long bright if
equipment failure or protected;
Battery capacity indicator (No. 8 Figure 2-1): 4 green lamps, each light
represent 25% of capacity. The four lights lit when capacity is 100%, if 75%,
the first left a lamp off, and the right three lights; if 50%, the left two lights out,
the right two lights; if 25 %, the left three lights off, the right one lights.
Table 2-4: LED Indicators Instructions
Battery
Statues
Protection
/ Alarm /
RUN ALM Capacity LED
Description
s
