Pylon Technologies Co., Ltd. Confidential Proprietary 10
Table 3-1 Tools and Meters
Screwdriver (Slotted, Phillips)
Multimeter
Wrench Clip-on Ammeter
Diagonal Pliers Insulating Tape
Pliers Thermometer
Clip Pliers Antistatic Wrist Ring
Strippers Ties
Technical Information
"Project Exploration Station Report", "Extra 2000 lithium iron phosphate Standby
Power User's Manual" and "installation and inspection reports".
3.1.3 Technical Preparation
Electrical Interface Checking
Connected directly to the battery device could be user equipments, switching
power supply or other power equipments. There are two typical interface device of
power line:
1. DC Backup Power Interfaces
If the battery directly connects to the user device, please check:
To check the user whether the device with DC backup power interface and
whether the output voltage electrical equipment meets the requirements in
voltage range of Table 2-6.
To confirm the maximum discharge current capability of user interface to the
device DC backup power, must be greater than the maximum discharge
curr
ent products in Table 2-6; if not, the limiting function is required.
To confirm the maximum operating current by battery-powered user
equipment must be less than the maximum discharge current products
mentioned in Table 2-7.
2. Switching Power Supply
If the battery is connected to switching power supply, it must be confirmed the
positive and negative
switching power connector, and measure whether the output
voltage meets the requirements in Table 2-6; and also recognizing the maximum
Extra2000LithiumIronPhosphateBatteryBackupManual
