10
Output request signal voltage ≤25V
CAN
500 Kbps. 120Ω. For connection to LV-HUB, inverter, or upper battery.
RS485
9600 or 115200 bps.120Ω. For connection to inverter, or slave battery.
Link Port 0, 1
for communication between multiple parallel batteries.
Definition of RJ45 Port Pin
These pins shall be NULL.
If not, may influence communication
between BMS and inverter.
Power Terminals
Power cable terminals: there are two pair of terminals
with same function, one connects to equipment, the
other one paralleling to other battery module for capacity
expanding.
For power cables uses water-proofed connectors. must
keep pressing this Lock Button while pulling out the
power plug.
