Pylontech US2000C User Manual

5
Basic Parameters
US3000C
Nominal Voltage (V)
48
Nominal Capacity (Wh)
3552
Usable Capacity (Wh)
3374.4
Dimension (mm)
442*420*132
Weight (Kg)
32
Discharge Voltage (V)
44.5 ~ 53.5
Charge Voltage (V)
52.5 ~ 53.5
Recommend Charge/Discharge Current (A)
37
Max. Charge/Discharge Current (A)
74
Peak Charge/Discharge Current (A)
90A@15sec
Communication
RS485, CAN
Depth of discharge (%)
95
Configuration (max. in 1 battery group)
16pcs
Working Temperature
0℃~50℃ Charge
-10℃~50℃ Discharge
Shelf Temperature
-20℃~60℃
Protective class
I
IP rating of enclosure
IP20
Humidity
5 ~ 95%(RH)
Altitude(m)
<2000
Certification
TÜV / CE / UN38.3/UL
Design life
10+ Years (25℃/77℉)
Cycle Life
>4,500 25℃
Reference to standards
IEC62619, IEC63056,
IEC62040, IEC62477-1,
UL1973,UL1642,VDE2510-50,
IEC61000-6-2,IEC61000-6-3,
UN38.3
