Pylontech US3000C Product Manual

4
2.3 LED Indicators Instructions
Status
●
Only the HUB is turned ON, it lights once.
●
No battery connected or at least one group is off line. When
battery group is reduced it will alarm (in red), but when
battery group is added in it will no alarm.
1 2 3 4 Green flash; connected battery groups number
● 1 group
● 2 groups
● ● 3 groups
● 4 groups
● ● 5 groups
● ● 6 groups
● ● ● 7 groups

Pylontech US3000C Specifications

General

Battery Type	Lithium Iron Phosphate (LiFePO4)
Nominal Voltage	48V
Capacity	74Ah
Discharge Current (Recommended)	37A
Discharge Current (Maximum)	74A
Communication	CAN, RS485
Cycle Life	6000 Cycles @ 25°C
Operating Temperature	-10°C to 50°C
Scalability	Up to 16 units in parallel
Certification	CE, UN38.3
