Pyramid PB1045X - PB645 X; PB845 X Features and Controls; CH 3;4 Controls and Connections; CH 1;2 Controls and Connections

10
pb645X
pb845X
features and controls
4 ch amp PB645X • PB845X
ch 1/2 crossover mode selector switch
ch 1/2 bass boost level control
ch 1/2 input level control
ch 1/2 high pass frequency control
ch 1/2 low pass frequency control
ch 3/4 crossover mode selector switch
ch 3/4 bass boost level control
ch 3/4 input level control
ch 3/4 high pass frequency control
ch 3/4 low pass frequency control
ch 1/2 high level inputs
power LED
speaker connections
power fuse
protection LED
ch 1/2 low level inputs
power terminals
ch 3/4 high level inputs
ch 3/4 low level inputs
Remote Bass Boost(PB645X without)
