Pyramid PB1045X - 2-Channel Stereo Input Connections; Using Low Level RCA Inputs; Using High Level Speaker Inputs

16
stereo input connections
2 ch amp PB445X • PB545X • PB945X
pb445X
pb545X
pb945X
using low level inputs
head unit
L/R Audio
Outputs
from spealer terminals
LL RR
using high level inputs
head unit
wiring harness
PLEASE NOTE! If using high
level inputs, do not use the
low level RCA inputs at the
same time!
