mono input connections
2 ch amp PB445X • PB545X • PB945X
pb445X
pb545X
pb945X
head unit
using low level inputs
PLEASE NOTE! If using high
level inputs, do not use the
low level RCA inputs at the
same time!
using high level inputs
To a second amplifier
Y Adaptors
head unit
wiring harnesswiring harness
To a second amplifier
RRLL
from spealer terminals
