Pyramid PB444X - Stereo Input Connections (PB446 X;PB449 X)

mono input connectionsstereo input connections
2 ch amp PB446X • PB449X
12
owner’s manual
using low level inputs
using high level inputs
us
us
L/R audio outputs
head unit
RLRL
from speaker terminals
wiring harness
t
head unit
PLEASE NOTE! If using
high level inputs, do not
use the low level RCA
inputs at the same time!
