Pyramid PB444X - Mono Input Connections (PB446 X;PB449 X)

mono input connections
2 ch amp PB446X •PB449X
stereo input connections
13
using low level inputs
using high level inputs
head unit
Y adaptors
to a second
amplifier
head unit
from speaker terminals
wiring harness
to a second
amplifier
wiring
harness
PLEASE NOTE! If using
high level inputs, do not
use the low level RCA
inputs at the same time!
LRLR
