Q-See H.264 NETWORK DVR User Manual

92 93
Parameter QT528 QT526 QT504
COMPRESSION Compression
Format
Standard H.264 Baseline
VIDEO Video In Composite 1.0V
p-p/75Ω,
BNC x 8
Composite 1.0V
p-p/75Ω,
BNC x 16
Composite
1.0V p-p/75Ω,
BNC x 4
Video Out COMPOSITE 1.0V p-p/75Ω, BNC x 2, VGA x 1
VGA Resolution 1280x1024, 1024x768, 800x600
Record
Resolution
NTSC: 352x240, 704x480
PAL: 352x288, 704x576
Display Frame
Rate
(per camera)
704x480 at 30FPS
Record Frame
Rate
(per camera)
NTSC: D1 30FPS CIF 30FPS
PAL: D1 25FPS CIF 25FPS
AUDIO Audio Input -8dB~ 22k, RCA X4
Audio Output -8dB~92dB, RCA X1
ALARM Alarm Input NO or NC 8CH NO or NC
16CH
NO or NC 4CH
Alarm Output 1CH
FUNCTION Record Mode Manual/Sensor/Timer/Motion Detection
Multi-Function Simultaneously Record, View Live or Recorded Video,
Playback, Back-up files, Monitor Remotely
INTERFACE Network
Interface
RJ45 (LAN, Internet)
Communication
Interface
RS485,
USB 2.0 x 2 (One for Backup, One for USB Mouse)
CONTROLS PTZ Control Yes
Remote Control Yes
DISK INFO Disk Type SATA x 2 (up to 2TB each) SATA x 1 (up to
2TB)
OTHER INFO Voltage 12V4A 12V5A 12V3A
Optimal
Temperature
32°F to 122°F 10°C to 50°C
10% to 90% Humidity
Average Power
Consumption
18W 30W 10W
Parameter QT518 QT5116 QT536
COMPRESSION Compression
Format
Standard H.264 Baseline
VIDEO Video In Composite 1.0V
p-p/75Ω,
BNC x 8
Composite 1.0V
p-p/75Ω,
BNC x 16
Composite 1.0V
p-p/75Ω,
BNC x 16
Video Out COMPOSITE
1.0V p-p/75Ω,
BNC x 2, VGA
x 1, HDMI,
Loopout x 8
COMPOSITE
1.0V p-p/75Ω,
BNC x 2, VGA x
1, HDMI,
COMPOSITE
1.0V p-p/75Ω,
BNC x 2, VGA
x 1, HDMI,
Loopout x 16
VGA Resolution 1920x1080, 1280x1024, 1024x768, 800x600
Record
Resolution
NTSC: 352x240, 704x480
PAL: 352x288, 704x576
Display Frame
Rate
(per camera)
704x480 at 30FPS
Record Frame
Rate
(per camera)
NTSC: D1 30FPS CIF 30FPS
PAL: D1 25FPS CIF 25FPS
AUDIO Audio Input -8dB~ 22k,
RCA X8
-8dB~ 22k, RCA
X16
-8dB~ 22k,
RCA X16
Audio Output -8dB~92dB, RCA X4 -8dB~92dB,
RCA X1
ALARM Alarm Input NO or NC 8CH NO or NC 16CH NO or NC 16CH
Alarm Output 4CH 4CH 4CH
FUNCTION Record Mode Manual/Sensor/Timer/Motion Detection
Multi-Function Simultaneously Record, View Live or Recorded Video,
Playback, Back-up files, Monitor Remotely
INTERFACE Network
Interface
RJ45 (LAN, Internet)
Communication
Interface
RS485, eSATA, Microphone
USB 2.0 x 2 (One for Backup, One
for USB Mouse)
RS485, eSATA
x 2, Microphone
USB 2.0 x
2 (One for
Backup, One for
USB Mouse)
CONTROLS PTZ Control Yes
Remote Control Yes
DISK INFO Disk Type SATA x 3 (up to 2TB each) SATA x 8 (up to
2TB each)
OTHER INFO Voltage 110/230V
Optimal
Temperature
50°F to 104°F 10°C to 40°C
10% to 90% Humidity
Average Power
Consumption
22W 36W 50W
