QDtech MSP0962 - Size Parameters; Electrical Parameters; Other Parameters

LCDWIKI MSP0962_MSP0963 Specification CR2023-MI2973
www.lcdwiki.com 6 / 12 V1.0
Panel Type
IPS
-
Resolution
240xRGBx198
pixels
Active Area
24.408(W)x20.137(H)
mm
Number of Colors(Max)
65K
-
Driver IC
ST7789H2
-
Display Interface
4-Line SPI
-
Pixel Size
0.1017(H)x0.1017(V)
mm
View Angle
ALL 0’ CLOCK
deg
Brightness(TYP)
300
cd/m
2
Backlight Type
White LED*4
-
Operation Temperature
-10~60
℃
Storage Temperature
-20~70
℃
3.2. Size Parameters
Item
Parameters
Unit
TFT Outline
Size
27.4±0.2(W)x27.0±0.2(H)x1.31±0.15(D)
( Excluding cables and adhesive backing)
mm
Module
Outline Size
NO Glass Cover Plate:
29.73(W)x28.14(H)x6.66(D) (including Pin Header)
Have Glass Cover Plate:
31.88(W)x31.88(H)x9.65(D) ( including Pin
Header)
mm
3.3. Electrical Parameters
Item
Parameters
Unit
Working Voltage
5.0/3.3V
V
Backlight Current
40
mA
Power
0.09
W
3.4. Other Parameters
Item
Parameters
Unit
SKU
NO Glass Cover Plate :
MSP0962
Have Glass Cover Plate :
MSP0963
-
Interface
8P 1.25mm slot interface
-
Weight(including package)
MSP0962: 21
MSP0963: 25
g
