QDtech MSP0962 - Product Outline Drawing; Msp0963(With Glass Cover Plate) Outline Drawing

lcdwiki.com
lcdwiki.com
RECORD
Date
NOTES:
1.DISPLAY TYPE:
2.VIEWING DIRECTION:
3.DRIVE IC:
4.POLARIZER MODE:
5.RESOLUTION:
6.INTERFACE:
7.UNMARKER TOLERANCE:
8.OPERATING TEMP:
REVISION
mm
深圳市全动电子技术有限公司
ShenZhen QDtech electronic technology Co.,LTD.
TITLE.
SKU.
LCM OUTLINE
REV.
UNIT SIZE
A4
DRG DATE
DRAWING
CHECK
APPROVE
V1.0
First release
2023-09-05
0.96" Circular IPS TFT
ALL O'CLOCK
TRANSMISSIVE/POSITIVE
240*RGB*198
SPI_4-Line
±0.2
-10℃~+60℃
ST7789H2
V1.0
2023-09-05
Joan
Green
Rose
240x198 Pixels
ST7789H2
0.96inch IPS Module
20.137(LCD AA)
24.408(LCD AA)
31.88(cover plate)
31.88(cover plate)
3.736
3.736
3.60
(connector)
1.20(PCB)
4.00(column)
1.31±0.15(LCD)
0.46(cover adhesive)
2.53(cover plate)
1.00(SMD Max)
1.15(Narrow
connector)
9.65(total thickness)
29.73(PCB)
23.10
28.14(PCB)
15.01
14.87
8.63
3.32
1.07
0.94
2-
∅2.50
2-
∅5.50
1
8
全动 电子
Front
Side
Back
LCDWIKI MSP0962_MSP0963 Specification CR2023-MI2973
4. PRODUCT OUTLINE DRAWING
4.1. MSP0963(with Glass Cover Plate) Outline Drawing
www.lcdwiki.com 7 / 12 V1.0
Picture 4 MSP0963 Outline Drawing
