QDtech MSP0962 - Msp0962(Without Glass Cover Plate) Outline Drawing

lcdwiki.com
lcdwiki.com
RECORD
Date
NOTES:
1.DISPLAY TYPE:
2.VIEWING DIRECTION:
3.DRIVE IC:
4.POLARIZER MODE:
5.RESOLUTION:
6.INTERFACE:
7.UNMARKER TOLERANCE:
8.OPERATING TEMP:
REVISION
mm
深圳市全动电子技术有限公司
ShenZhen QDtech electronic technology Co.,LTD.
TITLE.
SKU.
LCM OUTLINE
REV.
UNIT SIZE
A4
DRG DATE
DRAWING
CHECK
APPROVE
V1.0
First release
2023-09-06
0.96" Circular IPS TFT
ALL O'CLOCK
TRANSMISSIVE/POSITIVE
240(H)*RGB*198(V)
SPI_4-Line
±0.2
-10℃~+60℃
ST7789H2
V1.0
2023-09-06
Joan
Green
Rose
240x198 Pixels
ST7789H2
0.96inch IPS Module
3.60(connector)
1.20(PCB)
4.00(column)
1.31±0.15(LCD)
1.00(SMD Max)
1.15(Narrow connector)
6.66(total thickness)
23.10
15.01
14.87
8.63
3.32
2-
∅2.50
2-
∅5.50
1
8
全动 电子
Front
Side
Back
29.73(PCB)
27.40±0.2(BL)
24.408(LCD AA)
28.14(PCB)
27.00±0.2(BL)
20.137(LCD AA)
2.661±0.25
1.165
2.80±0.25
1.00
0.96" TFT
240*RGB*198
ALL 0' CLOCK
1.25
MSP0962
易撕贴
LCDWIKI MSP0962_MSP0963 Specification CR2023-MI2973
4.2. MSP0962(without Glass Cover Plate) Outline Drawing
Picture 5 MSP0962 Outline Drawing
www.lcdwiki.com 8 / 12 V1.0
