QEP 650XT - Troubleshooting Common Issues

– 10 –
TROUBLESHOOTING
OVERHEATING OF SAW:
1. Turn saw off and let it rest until motor is cool
to the touch.
2. Check and clean the ventilation slots,
removing blockage and dirt.
THE SAW DOES NOT START:
1. Check that power cord is properly plugged in.
2. Check outlet power source and circuit
breaker.
3. Make sure yellow safety key is fully pushed
into switch.
Q.E.P. CUSTOMER SERVICE:
1-866-435-8665
PARTS LIST
See exploded parts (p. 11)
PART # DESCRIPTION Qty
22650-1
Angle Guide 1
22650-2
Rip Guide 1
22650-3
Lock Piece for the Rip Guide 1
22650-4 Locking Clip for the Rip
Guide
1
22650-5
Cylinder Pin 1
22650-6 Cross Recessed Pan Head
Tapping Screw
1
22650-6A Assembled Rip Guide
(not pictured)
1
22650-7
Left Cutting Table 1
22650-8 Locking Knob for the Blade
Guard
1
22650-9
Blade Guard 1
22650-10
Hexagon Bolt 1
22650-11 Cross Recessed Pan Head
Tapping Screws
3
22650-12
Rack for the Blade Guard 1
22650-13
Right Cutting Table 1
22650-14 Support for Adjusting Miter
Cutting Angles
1
22650-15
Bases for the Supports 2
22650-16
Plain Washers 8
22650-17
Anti-loosing Nuts 8
22650-18 Support for Adjusting Miter
Cutting Angles
1
22650-19 Cross Recessed Pan Head
Tapping Screws
8
PART #
DESCRIPTION Qty
22650-20
Upper Frame 1
22650-21
Tube for Extension Tables 2
22650-22
Extension Table 1
22650-23 Pan Head Screw with Cross
Recess
2
22650-24
Pads 2
22650-25
Plain Washers 2
22650-26
Main Frame 1
22650-27
Splash Bafe 1
22650-28
Capacitor 1
22650-29
Rubber Washers 4
22650-30 Cross Recessed Pan Head
Tapping Screws
4
22650-31
Motor 1
22650-32
Oil Seal for Motor 1
22650-33
Plastic Nut 1
22650-34
Inner Flange 1
22650-35
Blade 1
22650-36
Outer Flange 1
22650-37
Hexagon Nut 1
22650-38
Fixing for the Protector 1
22650-39
Protector for the Switch 1
22650-40
Switch 1
22650-41
Power Cord Shelter 1
22650-42
PVC Feet 4
