BWT20 Qilin double swing handheld laser
29
"" in the upper right corner: Click to enter the corresponding LOGO number
and replace the LOGO.(It can be repeated before the shutdown,
and can not be changed after the shutdown)
Laser unlock code: When the laser is locked, it can be unlocked through this
interface. No need to connect the computer to unlock it can directly
input the unlock code provided by the laser manufacturer to
unlock.(Currently, only chuangxin laser unlocking is supported)
hardware configuration:
Password: 123456.
Laser power: The laser power used can be selected to retrieve the process package of this
laser.
Alarm point level conversion: can choose high and low level to remove the laser, chiller
and air pressure alarm.
Optical lock timing function: After opening this function, the optical lock will
automatically close for 15 minutes without operation. To close this
function requires to manually close the optical lock.
Process Package of Reference
Parameters:
1500W laser control Laser head control
order
number
Material and
thickness
power frequency duty cycle pattern frequency width
1
Stainless Steel 1.0 30% 3000HZ 100% ○ 10hz 1.6mm
Stainless Steel 2.0 60% 3000HZ 100% △ 10hz 2.6mm
Stainless Steel 3.0 90% 3000HZ 100% 10hz 3mm
2
Carbon steel 1.0 30% 3000HZ 100% ○ 10hz 1.6mm
Carbon steel 2.0 60% 3000HZ 100% △ 10hz 2.6mm
Carbon steel 3.0 85% 3000HZ 100% 10hz 3mm
3
Galvanized plate
1.0
35% 3000HZ 100% ○ 16hz 1.6mm
Galvanized plate
2.0
65% 3000HZ 100% △ 16hz 2.6mm
