Qlima P522 User Manual

N TECHNICAL DATA
To be used as indication, subject to modifications
Model
P 522 P 528 P 534 PH 534
Cooling capacity* kW 2.05 2.64 3.2 3.2
Heating capacity* 2.9
EER* 2.61 2.93 2.67 2.6
EE Class* W/W A A A A
COP* 2.8
COP Class* W/W A+
Power consumption in COOLING
mode
W 785 900 1200 1230
Power consumption in HEATING
mode
W 1035
Power consumption Standby
mode
W 0.5 0.5 0.5 0.5
Current nom. A 3.4 4.0 5.3 5.4
Mains V/Hz/F 220-240 / 50 / 1
Air delivery max. m ³ /h
300 300 330 300
Dehumidification max. ** L/h 0.6 1.1 1.5 1.5
Room size m³ 75 90 110 110
Compressor type rotary rotary rotary rotary
Refrigerant
type/gr/
GWP
R290 / 215
/ 3
R290 / 245
/ 3
R290 / 235
/ 3
R290 / 260
/ 3
CO2 equivalent tonnes 0.001 0.001 0.001 0.001
Thermostat range °C 18-32 18-32 18-32 18-32
Fan speeds 3 3 3 3
Max. Sound pressure level /
power level
dB(A) 56 / 65 56 / 65 56 / 65 57 / 65
Dimensions (w x h x d) mm
420 x 700 x
310
440 x 715 x
355
440 x 715 x
355
440 x 715 x
355
Weight kg 27 30.1 31 31
Unit protection IP X0 X0 X0 X0
Remote control yes yes yes yes
* Conform EN 14511
** Moisture removal at 35°C, 60% RH
4
62

Qlima P522 Specifications

General

Type	Monobloc mobile air conditioner
Timer	Yes
Noise level	65 dB
Number of speeds	3
Airflow (high speed)	330 m³/h
Refrigerating medium	R410A
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	0.7 l/h
Air conditioner functions	Cooling, Dehumidifying
Cooling temperature range	18 - 32 °C
Refrigerating medium weight	410 g
Suitable for room volume up to	75 m³
Cooling capacity in watts (max)	2200 W
Heating capacity in watts (max)	- W
Cooling energy efficiency (EER, W/W)	2.6
Heating energy efficiency (COP, W/W)	-
Current	3.7 A
AC input voltage	220-240 V
AC input frequency	50 Hz
Energy efficiency class (cooling)	A
Energy efficiency class (heating)	No
Hourly energy consumption (cooling)	0.8 kWh
Hourly energy consumption (heating)	- kWh
Product color	White

Weight and Dimensions

Depth	690 mm
Width	415 mm
Height	315 mm
Weight	24000 g
Package depth	844 mm
Package width	462 mm
Package height	357 mm
Package weight	28000 g
