FC0054606-00 A 1-1
1 Hardware and Software
Components
This chapter provides details about QLogic FC adapters for VMware, including:
“Hardware Components” on page 1-1
“Software Components” on page 1-3
“QLogic FC Adapters Supported on VMware ESX/ESXi” on page 1-4
Hardware Components
A typical QLogic FC adapter includes the following major components:
RISC processor
Static random access memory (SRAM)
Non-volatile memory (Flash)
Non-volatile random access memory (NVRAM) (On ISP25xx, NVRAM is
built into the Flash)
Transceivers
LEDs
Figure 1-1 shows the hardware components of a QLogic FC adapter and
Table 1-1 provides additional details of selected components.
