4 – Managing Switches
Using the Switch Data Window
4-6 59264-01 A
S
FDMI Enable Fabric Device Management Interface status. If enabled,
device information can be obtained, managed, and saved
through the fabric using Name Service Management
Server functions. QuickTools will report all FDMI informa-
tion reported by the entry switch, if FDMI is enabled on
the entry switch.
FDMI HBA Entry Limit Maximum number of HBAs that can be registered with a
switch.
Embedded GUI Enabled QuickTools web applet status. Enables or disables the
web applet on the switch.
Inactivity Timeout Number of minutes the switch waits before terminating an
idle command line interface session. Zero (0) disables
the time out threshold.
GUI Mgmt Enabled Web applet status. If disabled, the switch cannot be man-
aged using the web applet.
Telnet Enabled Telnet client status
SSH Enabled Secure Shell status. If enabled, an encrypted data path is
provided for command line interface sessions.
SSL Enabled Secure Sockets Layer status. If enabled, encryption for
switch management web applet and CIM sessions is pro-
vided.
CIM Enabled Common Interface Model status. The CIM agent is based
on the SNIA Storage Management Initiative Specification
(SMI-S), which is the standard for SAN management in a
heterogeneous environment.
FTP Enabled FTP status
Management Server Enabled Management server status.
SNMP Enabled SNMP enabled or disabled.
Call Home Enabled Call Home status. If enabled and configured, switches
can send alerts and events to pagers, and send Email.
Users can configure the type of events and where the
alerts are sent.
Zones/Security Group
Table 4-1. Switch Data Window Entries (Continued)
Entry Description
