4 – Managing Switches
Using the Switch Data Window
59264-01 A 4-7
A
Merge Auto Save If enabled, any zoning updates from the fabric will be
saved in permanent (non-volatile) memory as well as
temporary memory. If disabled, any zoning updates from
the fabric will be saved only in temporary memory and will
be lost after a switch reset.
Zoning Default Visibility N/A - does not apply to this switch
Default Zone Disables communication between ports and devices not
defined in the active zone set, or when there is no active
zone set.
Discard Inactive Automatically removes the previously active zone set
when a zone set is activated on a switch.
Implicit Hard Zoning Introduces hardware enforcement of zoning regardless of
type. All zones and all supported zone member types will
have hardware enforcement.
Security Auto Save N/A - does not apply to this switch
Security Fabric Binding Enable N/A - does not apply to this switch
Advanced Group
R_A_TOV Resource allocation timeout value
E_D_TOV Error detect timeout value
Number of Donor Groups Total number of donor port groups. A donor group is a set
of ports on a switch that can donate buffer credits to each
other.
Inactivity Timeout Number of minutes the switch waits before terminating an
idle command line interface session. Zero (0) disables
the time out threshold.
In-band Enabled In-band management status. Permits (True) or prevents
(False) a switch from being managed over an ISL.
Principal Switch If there is a domain ID conflict in the fabric, the switch
with the highest principal priority, or the principal switch,
will reassign any domain ID conflicts and establish the
fabric.
Table 4-1. Switch Data Window Entries (Continued)
Entry Description
