QNAP TS-131K User Manual

Component TS-131K TS-231K TS-431K
Drive compatibility 3.5-inch bays:
• 3.5-inch SATA hard disk drives
2.5-inch bays:
• 2.5-inch SATA hard disk drives
• 2.5-inch SATA solid-state drives
SSD cache acceleration
support
• 3.5-inch drive bays:1 • 3.5-inch drive bays:1
to 2
• 3.5-inch drive bays:1
to 4
Hot-swapping Supported
Network
Gigabit Ethernet ports 1 x GbE RJ45 2 x GbE RJ45
External I/O Ports & Expansion Slots
USB ports Front:
1 x USB 3.2 Gen 1 (5 Gbps)
Note
This USB port supports One Touch Copy.
Rear:
2 x USB 3.2 Gen 1 (5 Gbps)
Interface
Buttons • Power
• Reset
• USB One Touch Copy
Dimensions
Form factor Tower
Dimensions (H x W x D) 169 x 73 x 219 mm
6.65 x 2.87 x 8.62 in
169 x 102 x 219 mm
6.65 x 4.02 x 8.62 in
169 x 160 x 219 mm
6.65 x 6.3 x 8.62 in
Net weight 1.04 kg (2.29 lbs) 1.28 kg (2.82 lbs) 3 kg (6.61 lbs)
Others
Power supply unit 36W, 100-240V DC,
50/60 Hz
60W, 100-240V DC,
50/60 Hz
90W, 100-240V DC,
50/60 Hz
System battery CR2032 lithium battery (3V, 225 mAh)
Sound level 16.0 dB(A) 22.1 dB(A) 23.2 dB(A)
Note
The sound level was tested at a bystander position, which is
within one meter of the NAS. The test NAS operated at low
speed with the maximum number of drives installed.
Fans System: 1 x 50 mm, 12V
DC smart fan
System: 1 x 70 mm, 12V
DC smart fan
System: 1 x 120 mm,
12V DC smart fan
Operating temperature 0˚C to 40˚C (32˚F to 104˚F)
Relative humidity • Non-condensing relative humidity: 5% to 95%
• Wet-bulb temperature: 27˚C (80.6˚F)
TS-x31K User Guide
Product Overview 5

QNAP TS-131K Specifications

General

RAID support	No
Storage drive size	- \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	FAT32, HFS+, NTFS, exFAT, ext3, ext4
Storage drive interface	-
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	1
Supported storage drive interfaces	Serial ATA II, Serial ATA III
Flash memory	512 MB
Internal memory	1 GB
Internal memory type	DDR4
Fan voltage	12 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply location	External
Power consumption (sleep)	7.29 W
Power consumption (typical)	11.62 W
Power supply unit (PSU) capacity	36 W
Chassis type	Tower
Cooling type	Active
Fan diameter	50 mm
Product color	Turquoise, White
LED indicators	HDD, LAN, Status, System
Number of fans	1 fan(s)
Cable lock slot type	Kensington
Type	NAS
Noise level	15.8 dB
Device class	Home & Home Office
Share folder	CIFS/SMB
Backup features	Cloud, USB drive, iSCSI LUN
Browser supported	Mozilla Firefox, Microsoft Edge, Google Chrome, Apple Safari
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SSL/TLS, TLS
Cables included	AC, LAN (RJ-45)
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Operating system version	5.0.0
Operating system installed	QNAP QTS
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Processor cores	4
Processor family	Annapurna Labs
Processor frequency	1.7 GHz
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	219 mm
Width	73 mm
Height	161 mm
Weight	1160 g
Package weight	1990 g
