QNAP TS-453E Repair Manual

No. Component
(Quantity)
Screw Type
(Quantity)
Screwdriver
(Torque)
Attached To
7 LCD display module
(1)
Pan head
M2.5x3
(2)
Phillips #1
(3 kgf.cm / 2.60 lbf.in)
Chassis
8 Backplane
(1)
Pan head
M3x5
(12)
Phillips #2
(7 kgf.cm / 6.08 lbf.in)
Backplane tray
9 Backplane tray
(1)
Flat head
M3x4
(6)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Chassis
10 Top bracket
(1)
Flat head
M3x4
(6)
Phillips #2
(7 kgf.cm / 6.08 lbf.in)
Chassis
11 System fan
(3)
Flat head
M5x10
(12)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Rear panel
12 Rubber feet
(4)
Pan head
M5x10
(4)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Chassis
13 Chassis
(1)
- - -
14 Power supply unit
bracket
(1)
Flat head
M3x4
(2)
Phillips #2
(7 kgf.cm / 6.08 lbf.in)
Chassis
15 Power supply unit
(1)
Flat head
#6-32x5
(4)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Rear panel
16 Expansion card (PCIe
full height)
(1)
Pan head
M3x5
(1)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Rear panel
| NAS Repair Manual
Category D NAS Models 138

QNAP TS-453E Specifications

General

GPU	Intel UHD Graphics
Flash Memory	4 GB (Dual boot OS protection)
Drive Bays	4 x 3.5-inch SATA 6Gb/s, 3Gb/s
Hot-swappable	Yes
M.2 SSD Slot	2 x M.2 2280 PCIe Gen3 x1
SSD Cache Acceleration Support	Yes
Network Interface	2 x 2.5GbE RJ45
Form Factor	Tower
LED Indicators	Status, LAN, USB, HDD 1-4
Kensington Security Slot	Yes
Operating System	QTS 5.0
Processor	Intel Celeron J6412
CPU Architecture	64-bit x86
Memory	8 GB DDR4 (4 GB x 2)
Memory Slot	2 x SO-DIMM
Drive Compatibility	3.5-inch SATA hard disk drives, 2.5-inch SATA solid state drives
Maximum Internal Raw Capacity	64 TB (16 TB drive x 4)
Buttons	Power, Reset
Power Supply Unit	100-240V
Fan	1 x 120mm
Operating Temperature	0°C to 40°C (32°F to 104°F)
Operating Humidity	5% to 95% RH
