3.18 Install 30pF trimmer capacitor C1
Insert the component pins carefully and with the correct orientation which matches the
PCB.
Cut the small pin stubs on the underside (solder side) of the PCB, they only protrude a few
mm but when installed in the enclosure could be rather close to the aluminium floor.
